Side grinding

BAF 100

Hydraulically controlled machine for automatic side grinding of band, circular and gang saws in wet grinding execution

Side clearance angle, tooth face
0 - 7°
Side clearance angle, tooth back
0 - 7°
Tooth pitch
13 – 127 mm
Saw blade length
from approx. 5'600 mm (standard)
Request a quoteDatasheet (PDF)
BAF 100

Description

The hydraulically controlled side grinding machine type BAF 100 impresses in daily use with its easy and uncomplicated operability as well as its outstanding precision, accessibility and durability.

Highlights

  • Compact, robust, and durable machine design for maximum reliability.
  • Full enclosure with intensive water or oil cooling for optimal heat dissipation.
  • Strong blade clamping with automatic force relief during feed to prevent material damage.
  • Automatic, electrically controlled blade height adjustment for precise results.
  • Simple and user-friendly operation via a colorful LCD touch panel (PLC control).
  • High grinding accuracy and excellent surface quality through the use of CBN or diamond grinding wheels.
  • Flexibly adjustable grinding parameters for various applications and tooth profiles.

    Hydraulic drive for:

  • Precise blade feed and dog lifting during the return movement.
  • Continuously adjustable grinding head feed speed for optimal control of grinding processes.
  • Reliable blade clamping and additional clamping for stabilization during grinding.

Applications

Grinding-wheel feed is at the top.
Grinding-wheel feed is at the top.
